All Sensor Graphs
RUMS is ONLINE. Latest Sampling: 25-jun-2017 08:43:16
| Status | Sensor Name | Description | Current Value | Unit | Alarm |
|---|---|---|---|---|---|
 | Compressed Air Flow | Compressed Dry Air Flow after dryer in 280. | -4.3 | scfm | Compressed Air Flow Low (<10.0) |
 | LN 1 Level | Liquid nitrogen level in vessel 1 (contact Mike Caputo of Alliance Gas 510-533-9353) | 157.5 | inches of w.c. | |
| LN 2 Level | Liquid nitrogen level in vessel 2 (contact Mike Caputo of Alliance Gas 510-533-9353) | 78.1 | inches of w.c. | |
| EF12 | Lab exhaust alarm (zero indicates no alarm, i.e. exhaust is on). | 0 | on/off | |
| EF34 | Silane exhaust alarm (zero indicates no alarm, i.e. exhaust is on). | 0 | on/off | |
| Low Level Gas Warn | TGM Low Level Gas Warn. | 0 | on/off | |
| AWN Chemical Low Alarm | Acid Waste Neutralizer NaOH and H2SO4 levels. | 0 | on/off | |
| AWN General Alarm | Acid Waste Neutralizer general alarm. | 0 | on/off | |
| AWN Surge Tank Level | Acid Waste Neutralizer Surge Tank level. | 273.2 | gal | |
| AWN Surge Tank pH | Acid Waste Neutralizer Surge Tank pH. | 7.9 | pH | |
| Compressed Air Dew Point | Compressed Dry Air dew point after dryer in 280. | -75.6 | F | |
| Compressed Air General Alarm | Compressed Dry Air General Alarm in 280. | 0 | on/off | |
| Compressed Air N2 Backup | Compressed Dry Air N2 backup valve. | 0 | on/off | |
| Compressed Air Pressure | Compressed Dry Air Pressure in 280. | 112.7 | psi | |
| DI Makeup Flow | Flow rate from the RO system to the DI system. | -0 | gpm | |
| DI Resistivity | Deionized Water final resisitivity in 280. | 17.5 | MOhm-cm | |
| DI Tank Level | Deionized Water level (both tanks). | 2205.6 | gal | |
| PCW Flow | Process Cooling Water supply flow rate in 280. | 354.5 | gpm | |
| PCW General Alarm | Process Cooling Water general alarm in 280. | 0 | on/off | |
| PCW ICW Crossover | Process Cooling Water FCV in 280. | 0 | on/off | |
| PCW Pressure | Process Cooling Water supply pressure in 280. | 91.3 | psi | |
| PCW Resistivity | Process Cooling Water resistivity in 280. | 201.1 | kOhm-cm | |
| PCW Temperature | Process Cooling Water temperature in 280. | 61.2 | F | |
| Process Vacuum | Process Vacuum pressure. | 26.2 | inHg | |
| N2 Flow Rate | Nitrogen flow rate at S&R cage. | 1742.3 | slpm | |
| N2 Pressure | Nitrogen pressure at S&R cage. | 101.9 | psi | |
| Argon Pressure | Argon pressure in 395 (in alarm means lag-bottle is sourcing). | 58.6 | psi | |
| N2 Oxygen Concentration | Oxygen concentration of the process nitrogen. | 0.4 | ppm | |
| O2 Flow Rate | O2 Flow Rate at S&R cage. | 3.6 | slpm | |
| O2 Pressure | O2 Pressure at S&R cage. | 38.6 | psi | |
| Cory Hall N2 Flow Rate | Cory Hall N2 flow rate. | 412.5 | lpm | |
| HMMB N2 Flow Rate | N2 flow rate to Hearst Memorial Mining Building. | 60.3 | lpm | |
| H2 Pressure | Pressure of lab hydrogen system. | 178 | psi | |
| 391-R1 Temperature | Temperature of the refrigerator 391-R1 | 27.5 | F | |
| 391-R2 Temperature | Temperature of the refrigerator 391-R2 | 32.2 | F | |
| Flood Sensor 168 | Plumbing room flood sensor in 168. | 0 | on/off | |
| GCAWS AC Secondary H20 | Water detection switches in the GCAWS AC trays above 384. | 0 | on/off | |
| Gas Cabinet Alarm L3 | State of gas cabinets in the L3 gas vault. | 0 | on/off | |
| Gas Cabinet Alarm L5 | State of gas cabinets in the L5 gas vault. | 0 | on/off | |
| Lab 3 Relative Humidity | Relative humidity, third floor. | 51.6 | percent | |
| Lab 3 Temperature | Temperature, third floor. | 66.5 | F | |
| Lab 5 Relative Humidity | Relative humidity, fifth floor. | 50.1 | percent | |
| Lab 5 Temperature | Temperature, fifth floor. | 66 | F | |
| NH3 599 Weight lbs | Weight of NH3 Cylinder in 599. | 166.3 | lbs | |
| UV210 Usage | UV210 usage. | 8.1 | mL | |
| UV26 Usage | UV26 Usage. | -200 | mL | |
| Test | RUMS test channel (for internal use only). | 0 | on/off |
